Single-Core IMQ Approved Double-insulated FEP Cables

FEP double-insulated heat resistant cable for internal wiring of Class II electrical and lighting appliances and devices.

CABLE STRUCTURE

  • Flexible rope conductor with electrolytic tinned copper.
  • FEP insulation type FR5F in compliance with CEI 20-51 requirements.
  • Marking : SALCAVI TECHNIC SPA ITALY IEMMEQU FR5F 180°

High Temperature Cables : 150 - 250°C: Single-Core IMQ Approved Double-insulated FEP Cables

APPLICATIONS


These wires are allowed to use for internal and fixed wiring of Class II electrical appliances or lamps and luminaries everywhere the temperature on conductor is not greater than the rated temperature.The laying in conduit or tubes is permitted. Cables for immersion in oil, gasoline and hydrocarbons.

  • Test voltage

    Test voltage
    2500 V

  • Rated temperature

    Rated temperature
    180°C

  • Short-circuit temperature

    Short-circuit temperature
    250°C

  • Minimum bending radius

    Minimum bending radius
    8 x D

  • IMQ

    IMQ
    License No. CA01.00647

  • Rated voltage

    Rated voltage
    450/750 V

  • Available types of packaging
    (Minimum supply: 5 Km)
  • Barrel
  • Reels
