High Temperature Cables: 105 - 150°C
Multi-Core SI-TECHPRENE Cables

CABLE STRUCTURE

• Electrolytic tinned copper stranded conductor (class 5), complying with IEC 60228 standard
• Halogen-free cross-linked polyolefin insulation with low emission of fumes and without toxic and acid gases. Rated temperature : - 40 ÷150 °C at fixed installations and for general uses ( 3000 h ), class E of temperature for wiring of electrical engines ( 120 °C for 20.000 hours as per CEI EN 62114), peak temperature 170°C only for short time.
• Special halogen-free cross-linked rubber outer sheath, with low emission fo fumes, and no toxic and acid gases, moreover a good resistance to a wide range of chemical substances and UV exposure (a continuous and long exposure to UV lamps, fluorescent lamps or any lamp with high spectral UV component is not permitted).
• Marking : SALCAVI TECHNIC SPA – ITALY  SI-TECHPRENE  RATED VOLTAGE  SIZE OF CONDUCTOR  HT 155°C  -  YEAR

Rated voltage
300/500 V, 450/750 V or 0.6/1 kV

Test voltage
2.5 kV or 5 kV

Rated temperature
120°C or 155°C

Short-circuit temperature
250°C

Minimum bending radius
12 x D
